geared 10 " electric brushless wheel motor for medical industry

10" 110mm brushless electric wheel motor suitable for electric conversion of wheelchairs, hospital beds or any rolling machine used in the medical or industry environment to reduce hardness :

  • Leisure (Golf cart, stroller, terrestrial drone)
  • Medical (wheelchair, medical bed, stretcher)
  • Comes with inflatable tire
  • 6 holes support for disc brake (delivered without the brake)


Rated power: 300W | Dropout : 110mm | Cable : 20cm

Read moreShow less
€299.00 (tax incl.)
Rupture de stock
Reference:
000394
You may also like
Brushless electric hub motor 3000W 130Nm 45km/h 48V to 72V Brushless electric hub motor 3000W 130Nm 45km/h 48V to 72V Brushless electric hub motor 3000W 130Nm 45km/h 48V to 72V

€549.00 (tax incl.)
3000W brushless electric hub motor for electrifying light vehicles, quadricycles, quads, robots, machines, etc. Ideal for building a license-free electric vehicle or a heavy-duty transport vehicle. 200Nm torque. Kv...
Agriculture machine electric motor 3000W BLDC Agriculture machine electric motor 3000W BLDC Agriculture machine electric motor 3000W BLDC

€399.00 (tax incl.)
3000W electric wheel motor brushless BLDC for wheelbarrow and agricultural machines, ideal for decreasing Human effort at work. Allows to carry up to 400kg under 48V DC, max torque 120Nm Including agriculture tire...
5000W rear wheel motor agricultural and industrial 5000W rear wheel motor agricultural and industrial 5000W rear wheel motor agricultural and industrial

€460.00 (tax incl.)
This 5000W motor gets 55mmm magnets and can accepts up to 5000W power. Weight : 9,8 kg | dropout : 150mm Pmax = 5000W / Pnom = 4000W Max torque = 170N.m Delivered with a 200mm cable length
Description

This electric drive wheel has been designed for the electrification of any recreational or medical device.

600W power will allow you to electrified any hospital beds, wheelchairs, stretcher or any other rolling base.

The tire provides shock absorption and a comfortable ride.

This brushless motor is a geared motor, which offer a great torque at low speed.

The external wheel diameter will be between 250mm and 320mm depending on tire choice.

This motor can fully meet the criteria to reduce hardness at work.

You can easily and quickly reduce these risks by electrifying your tools.

2D Drawings of the engine:

Read moreShow less
Product Details
000394

Data sheet

Guarantee
2 ans
Paires de pôles magnétiques
15
Couple max en 36V
25 N.m
Mass
3.4 kg
Technologie moteur
Brushless direct drive
Rendement max
85%
Tension Min
24V
Permissible voltages
24V, 36V et 48V
Entraxe fourche min/max
115mm / 145mm
Motor Kv (RPM / V)
8.33 Tr/min/Volt
Motor power range
200 - 1000W
Hall sensors
OUI
Waterproof grade
IP54
Nombre d'aimants
30
Motor axle
14x10mm
Vitesse max sous 24V
6 Km/h
Vitesse max sous 36V
10 Km/h
48V max speed
20 Km/h
